Rean-Neutrik
Nickel Stereo 1/4" Jack -Large Cable Outlet - NYS240L
3 pole 3.5 mm cable jack, metal handle, max. cable O.D. 6 mm
ProductTitle :NYS240L
Connection Type : Jack
Gender :female
|
MechanicalCable O.D. :6 mm
Insertion force :≤ 20 N
Withdrawal force :≥ 10 N
Lifetime :1000 mating cycles
|
ElectricalDielectric strength : 0.5 kVdc
Insulation resistance : ≥ 1 GΩ
Rated current :depends on mated connector
Contact resistance :depends on mated connector
|
MaterialContact plating : Nickel
Contacts :Brass (CuZn39Pb3)
Shell : Brass (CuZn39Pb3)
Shell plating :Nickel
Strain relief : SnCe plated, crimp type
Insulation : Thermoplastic
|
EnvironmentalSolderability : Complies with IEC 68-2-20
Temperature range : -25 °C to +70 °C
|
